How to prep a 3rd gen harness
#152
Supreme Member
iTrader: (4)
Re: How to prep a 3rd gen harness
Im VERY confused here, but it's harder since i dont have any harnesses to look at.
My car was a 305 TBI, 700r4 car. But now it's got a carbed 350 and a T56 in it. To do the T56 I just got lazy on the wiring and jsut put the two big giant purple wires together. Always said I would do the rest of it later, but never did or felt like I really needed to.
So you keep saying to get a harness that matches the original transmission to the vehicle. Should I get a dash harness to match a T5? Or a T56? Or should I get a 4l60e donor harness since that matches the dash harness? Would I be better off getting a T5 dash harness?
I REALLY, REALLY hate wiring, so I avoid it like the plague. But Im thinking since I dont have any AC or cruise control and as ingle fan and so on that it SHOULD be pretty easy.... But Im not really sure what harness I need to start with.
Ugh...
My car was a 305 TBI, 700r4 car. But now it's got a carbed 350 and a T56 in it. To do the T56 I just got lazy on the wiring and jsut put the two big giant purple wires together. Always said I would do the rest of it later, but never did or felt like I really needed to.
So you keep saying to get a harness that matches the original transmission to the vehicle. Should I get a dash harness to match a T5? Or a T56? Or should I get a 4l60e donor harness since that matches the dash harness? Would I be better off getting a T5 dash harness?
I REALLY, REALLY hate wiring, so I avoid it like the plague. But Im thinking since I dont have any AC or cruise control and as ingle fan and so on that it SHOULD be pretty easy.... But Im not really sure what harness I need to start with.
Ugh...
Last edited by InfernalVortex; 02-09-2015 at 09:16 PM.
#153
Supreme Member
iTrader: (11)
Join Date: Sep 1999
Location: NJ
Posts: 4,345
Received 298 Likes
on
234 Posts
Car: 92 Firebird
Engine: 4.8 LR4
Transmission: T56
Axle/Gears: 3.45 9 Bolt
Re: How to prep a 3rd gen harness
There never was a T56 3rd gen, i'd have to be the T5, but you can get by without. I extended the wires from the PND connector at the console over to the clutch pedal to hook up to a NSS when I did the T56 conversion back in 1999 or something
#154
Member
Join Date: Aug 2009
Location: this car
Posts: 332
Likes: 0
Received 0 Likes
on
0 Posts
Car: 85 Z28
Engine: 93 LT1
Transmission: Auto
Axle/Gears: 3.73 01 SS
Re: How to prep a 3rd gen harness
I need to figure out 95 or so lt1 with a 4l60. i guess a early model lt1 ecm and setup would work. The upgrade to the pcm in 94-?? is pointless because the 4l60 aka 700r4 doesnt use it.
#155
Supreme Member
Thread Starter
iTrader: (24)
Join Date: Jun 2005
Location: NC
Posts: 7,883
Likes: 0
Received 58 Likes
on
42 Posts
Car: 92 Firebird
Engine: Supercharged 6.0
Transmission: T56
Axle/Gears: 8.8 3.73
Re: How to prep a 3rd gen harness
Im VERY confused here, but it's harder since i dont have any harnesses to look at.
My car was a 305 TBI, 700r4 car. But now it's got a carbed 350 and a T56 in it. To do the T56 I just got lazy on the wiring and jsut put the two big giant purple wires together. Always said I would do the rest of it later, but never did or felt like I really needed to.
So you keep saying to get a harness that matches the original transmission to the vehicle. Should I get a dash harness to match a T5? Or a T56? Or should I get a 4l60e donor harness since that matches the dash harness? Would I be better off getting a T5 dash harness?
I REALLY, REALLY hate wiring, so I avoid it like the plague. But Im thinking since I dont have any AC or cruise control and as ingle fan and so on that it SHOULD be pretty easy.... But Im not really sure what harness I need to start with.
Ugh...
My car was a 305 TBI, 700r4 car. But now it's got a carbed 350 and a T56 in it. To do the T56 I just got lazy on the wiring and jsut put the two big giant purple wires together. Always said I would do the rest of it later, but never did or felt like I really needed to.
So you keep saying to get a harness that matches the original transmission to the vehicle. Should I get a dash harness to match a T5? Or a T56? Or should I get a 4l60e donor harness since that matches the dash harness? Would I be better off getting a T5 dash harness?
I REALLY, REALLY hate wiring, so I avoid it like the plague. But Im thinking since I dont have any AC or cruise control and as ingle fan and so on that it SHOULD be pretty easy.... But Im not really sure what harness I need to start with.
Ugh...
So for your auto to T56 swap, you'd use an auto engine harness and still follow the standard auto to manual wiring changes for the dash. All of it comes from the old auto shifter connector
Top two are 12ga, these go to the clutch switch at the pedal. Splicing them together works, but the safety switch is bypassed
Middle two are back-up lights. Connect these to the back-up switch on the trans
Bottom two are P/Neutral. Ignore these
Thats it
I need to figure out 95 or so lt1 with a 4l60. i guess a early model lt1 ecm and setup would work. The upgrade to the pcm in 94-?? is pointless because the 4l60 aka 700r4 doesnt use it.
92-93 SD, similar to TPI SD
94-95 OBDI <-- most common for swaps
96-97 OBDII
Only the earliest can control the lock-up function of a 700R4/4L60. The latter two can control a fully electronic 4L60E, but not an older trans
If your 95 engine came with the trans, its a 4L60E, not a 4L60, so youd need a 94-95 PCM. 96-97 PCMs require additional parts that didnt come on the older engines such as a crank pos sensor mounted in the timing cover. 96-97 engines can still use the 94-95 PCM, even with the newer harness, but the reverse wont work
#156
Member
Join Date: Aug 2009
Location: this car
Posts: 332
Likes: 0
Received 0 Likes
on
0 Posts
Car: 85 Z28
Engine: 93 LT1
Transmission: Auto
Axle/Gears: 3.73 01 SS
Re: How to prep a 3rd gen harness
Only the earliest can control the lock-up function of a 700R4/4L60. The latter two can control a fully electronic 4L60E, but not an older trans
If your 95 engine came with the trans, its a 4L60E, not a 4L60, so youd need a 94-95 PCM. 96-97 PCMs require additional parts that didnt come on the older engines such as a crank pos sensor mounted in the timing cover. 96-97 engines can still use the 94-95 PCM, even with the newer harness, but the reverse wont work
If your 95 engine came with the trans, its a 4L60E, not a 4L60, so youd need a 94-95 PCM. 96-97 PCMs require additional parts that didnt come on the older engines such as a crank pos sensor mounted in the timing cover. 96-97 engines can still use the 94-95 PCM, even with the newer harness, but the reverse wont work
#157
Supreme Member
Thread Starter
iTrader: (24)
Join Date: Jun 2005
Location: NC
Posts: 7,883
Likes: 0
Received 58 Likes
on
42 Posts
Car: 92 Firebird
Engine: Supercharged 6.0
Transmission: T56
Axle/Gears: 8.8 3.73
Re: How to prep a 3rd gen harness
If you're going to dumb it down to keep the archaic trans, Id cut a hole in the intake for a distributor and run your TPI electronics
No, the block and heads are no better/worse for any year LT1. 92-93's had a slightly different intake/rail and the TB had a stud for a TV cable
No, the block and heads are no better/worse for any year LT1. 92-93's had a slightly different intake/rail and the TB had a stud for a TV cable
#158
Member
Join Date: Aug 2009
Location: this car
Posts: 332
Likes: 0
Received 0 Likes
on
0 Posts
Car: 85 Z28
Engine: 93 LT1
Transmission: Auto
Axle/Gears: 3.73 01 SS
Re: How to prep a 3rd gen harness
So you really suggest cutting a distributor hole in my intake? Aren't there any advantages to running the 92-93 ecm over the tpi ecm?
#159
Supreme Member
Thread Starter
iTrader: (24)
Join Date: Jun 2005
Location: NC
Posts: 7,883
Likes: 0
Received 58 Likes
on
42 Posts
Car: 92 Firebird
Engine: Supercharged 6.0
Transmission: T56
Axle/Gears: 8.8 3.73
Re: How to prep a 3rd gen harness
Not really. Its a sealed ECM where your TPI isnt. I cant see rebuilding a harness just for that
#161
Member
Join Date: Aug 2009
Location: this car
Posts: 332
Likes: 0
Received 0 Likes
on
0 Posts
Car: 85 Z28
Engine: 93 LT1
Transmission: Auto
Axle/Gears: 3.73 01 SS
Re: How to prep a 3rd gen harness
I was just going to do the rewire myself. I don't have the money to have a harness professionally rewired. I barely have enough to get the parts I need in the first place. Just exploring different possibilities.
#162
Member
iTrader: (1)
Join Date: Jun 2009
Location: Pennslyvania
Posts: 263
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1984 camaro Z28
Engine: 355 SBC
Transmission: 700 r-4
Axle/Gears: Strange 3:73 posi
Re: How to prep a 3rd gen harness
Hi I'm putting a lt1 starter in my 84 z28 w/ carbed 355 vortec motor so I do not need to change any wiring except for the starter . I've read that you only need the batt and purple wire , what happens to the other starter wire? Thanks for your help.
#163
Senior Member
Re: How to prep a 3rd gen harness
Which other wire? Big wire from battery to starter, purple wire from the C-100 to the starter and there are 2 more red wires from the C-100 that go to the same lug as the big + wire on the starter, they are your hots for your chassis side (lights etc).
#164
Re: How to prep a 3rd gen harness
Can anyone help me. Is there anyone i could pay to make me a Carburated wiring harness for my 1988 camaro. The car used to have a 350 TBI and i did an engine swap to a 355 with 4bbl carb. I would like a harness that eliminated the ecu and keeps my accessories running like stock like ac and gauges. PM me if anyone interested. Thank You
#165
Member
Join Date: Dec 2007
Location: mattoon illinois
Posts: 199
Likes: 0
Received 0 Likes
on
0 Posts
Car: 92camaro,86 camaro
Engine: 355
Transmission: 700r4
Re: How to prep a 3rd gen harness
I'm trying to figure this out. if you use the sts fuse box you are making a stand alone harness for the engine right? so the main fuse box of the car will control inside and outside light radio and that's it right?
#166
Senior Member
Re: How to prep a 3rd gen harness
I made a standalone harness.
From my C-100 (the larger half) I have the starter solenoid wire, my ign hot wire and two wires that are the (+) wires the power everything in the chassis, like your lights, ctsy stuff etc.
I had pocket make me a nice little relay/fuse block that I put in a fairly out of sight spot on the frame rail next to the battery.
I ran my chassis (+) wires to their own dedicated in line mega fuses off the battery to get rid of the fuse-links.
On your STS fuse block you'll have the main power in and then it distributes out from there, I only needed 3 relays (ign, fuel pump and fan).
I enjoyed the wiring honestly, and will possibly end up doing a harness for a friend's 91 BMW to LS swap if he gets the parts together.
From my C-100 (the larger half) I have the starter solenoid wire, my ign hot wire and two wires that are the (+) wires the power everything in the chassis, like your lights, ctsy stuff etc.
I had pocket make me a nice little relay/fuse block that I put in a fairly out of sight spot on the frame rail next to the battery.
I ran my chassis (+) wires to their own dedicated in line mega fuses off the battery to get rid of the fuse-links.
On your STS fuse block you'll have the main power in and then it distributes out from there, I only needed 3 relays (ign, fuel pump and fan).
I enjoyed the wiring honestly, and will possibly end up doing a harness for a friend's 91 BMW to LS swap if he gets the parts together.
#167
Member
Join Date: Dec 2007
Location: mattoon illinois
Posts: 199
Likes: 0
Received 0 Likes
on
0 Posts
Car: 92camaro,86 camaro
Engine: 355
Transmission: 700r4
Re: How to prep a 3rd gen harness
so the connector c207 plugs into the third Gen computer right? so if I don't habe one can I just got to a salvage yard and pick one up?
#168
Senior Member
iTrader: (3)
Re: How to prep a 3rd gen harness
Yes, you could go to a salvage yard and cut this connector out if you're missing yours from a previous modification.
#169
Member
Join Date: Dec 2007
Location: mattoon illinois
Posts: 199
Likes: 0
Received 0 Likes
on
0 Posts
Car: 92camaro,86 camaro
Engine: 355
Transmission: 700r4
Re: How to prep a 3rd gen harness
I don't have a computer I do have the harness. I wanted to know if I can just. pick up any computer? sorry for the miss understanding
#171
Supreme Member
Thread Starter
iTrader: (24)
Join Date: Jun 2005
Location: NC
Posts: 7,883
Likes: 0
Received 58 Likes
on
42 Posts
Car: 92 Firebird
Engine: Supercharged 6.0
Transmission: T56
Axle/Gears: 8.8 3.73
Re: How to prep a 3rd gen harness
Billy, PM me. I can put the AC in it too like your other thread asked
Some cars need to add a fuseblock for the conversion such as 82-87 carb cars. 85-92 EFI cars have sufficient fuses in the stock block under the dash
The Caddy fuseblock is a compact option for those that need the fuseblock
You're mostly correct, but there are a few direct connections from the ECM/PCM that hit the C207 such as the ECU fuse, speedo, MIL, P/Neutral
Depends what you're doing. Carb conversions dont require a computer at all. TPIs can use an box with the right number, but the PROM/MEMCAL have to be correct for the engine. LT1s are pretty flexible, LSx also meet a certain range but also several V6 boxes can be used with a reflash
Its linked in the LS1 swap sticky
I'm trying to figure this out. if you use the sts fuse box you are making a stand alone harness for the engine right? so the main fuse box of the car will control inside and outside light radio and that's it right?
The Caddy fuseblock is a compact option for those that need the fuseblock
so the connector c207 plugs into the third Gen computer right? so if I don't habe one can I just got to a salvage yard and pick one up?
C207 connects the passenger side of the engine harness with the IP harness. The ECM connectors have some wiring connected in there as well, but C207 does not connect to the ECM directly.
Yes, you could go to a salvage yard and cut this connector out if you're missing yours from a previous modification.
Yes, you could go to a salvage yard and cut this connector out if you're missing yours from a previous modification.
I don't have a computer I do have the harness. I wanted to know if I can just. pick up any computer? sorry for the miss understanding
Why isn't this a sticky?
#172
Junior Member
iTrader: (1)
Join Date: Jul 2007
Location: Edinburg, TX
Posts: 44
Likes: 0
Received 1 Like
on
1 Post
Car: 91 Firebird convertible
Engine: 350 tpi
Transmission: 700 r4
Axle/Gears: 3.73's
Re: How to prep a 3rd gen harness
So the other connectors are just cancelled on the ecm I only keep the c207 connector right?
#173
Supreme Member
Thread Starter
iTrader: (24)
Join Date: Jun 2005
Location: NC
Posts: 7,883
Likes: 0
Received 58 Likes
on
42 Posts
Car: 92 Firebird
Engine: Supercharged 6.0
Transmission: T56
Axle/Gears: 8.8 3.73
Re: How to prep a 3rd gen harness
With a carb conversion or alternate EFI swap, then yes, all the old ECM connectors are removed. The C207 is needed for all EFI conversions and most carb conversions
#174
Junior Member
Join Date: Jun 2011
Location: Maryland,DMV
Posts: 20
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1989 Iroc-z convertible
Engine: lb9
Transmission: auto
Re: How to prep a 3rd gen harness
Hey does anyone have contact info for Pocket?I'm interested in getting a harness made.
I sent a pm no answer yet
I sent a pm no answer yet
#175
Junior Member
Join Date: Mar 2011
Location: Stockton, CA
Posts: 22
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1991 Camaro RS TBI Convertible
Engine: V8 305 5.0
Re: How to prep a 3rd gen harness
Im more of a visual person when it comes to DIY's sometimes as the wiring gets me confused. Anyone have a picture of the C207 and VSS buffer box bypass you talked about? Just need to get my gauges working, I found the buffer box but got confused on how I am suppose to wire this. LT1 PCM > C100? bridge connectors on VSS buffer box only? Thank you for any help you can provide. its the last thing I need as i need to bleed air out of the LT1 but without the gauge working I am not sure what temp its running at.
#179
Junior Member
Join Date: Mar 2011
Location: Stockton, CA
Posts: 22
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1991 Camaro RS TBI Convertible
Engine: V8 305 5.0
#180
Junior Member
iTrader: (1)
Join Date: Jul 2013
Location: Newburgh, IN
Posts: 77
Likes: 0
Received 0 Likes
on
0 Posts
Car: 89 Formula WS6
Engine: LQ4 h/c/i
Transmission: TH-FO-HUNNIT
Axle/Gears: 3.73
Re: How to prep a 3rd gen harness
Hey Pocket, if I am keeping my lights and all of those related plugs, I can just leave those on the C100 and just call that part good right? Finished my LS harness and starting on my third gen harness and going to use this guide to clean it up and just wondered about all of the lighting wires and all that. Thanks in advance dude!
#181
Junior Member
Join Date: Mar 2016
Location: Owensboro, Ky
Posts: 1
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1987 Tran Am
Engine: LQ4
Transmission: T56
Axle/Gears: 3.73
Re: How to prep a 3rd gen harness
thanks for the great info, but I have a few questions. im doing a lq4 swap in my 87 T/A and I want to use the stock fan and fuel pump relays, how do I wire these up , what wires do I keep out of the factory T/A engine harness? I also am going to use a t56 and the motor harness had a auto trans, how to wire up from the speed sensor to the ECM. thanks guys for the help, Im trying to get this car done before LS Fest 2016.
#182
Supreme Member
iTrader: (1)
Join Date: Feb 2003
Location: Marietta, GA
Posts: 2,024
Likes: 0
Received 1 Like
on
1 Post
Car: 92 Z28
Engine: LS1
Transmission: T56
Axle/Gears: 3.73 10 bolt
Re: How to prep a 3rd gen harness
Hey Pocket, if I am keeping my lights and all of those related plugs, I can just leave those on the C100 and just call that part good right? Finished my LS harness and starting on my third gen harness and going to use this guide to clean it up and just wondered about all of the lighting wires and all that. Thanks in advance dude!
thanks for the great info, but I have a few questions. im doing a lq4 swap in my 87 T/A and I want to use the stock fan and fuel pump relays, how do I wire these up , what wires do I keep out of the factory T/A engine harness? I also am going to use a t56 and the motor harness had a auto trans, how to wire up from the speed sensor to the ECM. thanks guys for the help, Im trying to get this car done before LS Fest 2016.
https://www.thirdgen.org/forums/ltx-...formation.html
Cable driven speedo you need a converter box. I'm sure this is covered somewhere, but I can't find the thread.
I'm just reposting Pockets info from other threads btw
#183
Junior Member
Join Date: Mar 2016
Location: Ontario, Canada
Posts: 11
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1987 Camaro
Engine: 4.8L LS
Transmission: 4l60E w/Shift Kit
Axle/Gears: 4th Gen Rear, 3.73 Posi
Re: How to prep a 3rd gen harness
Hey guys,
I had a guy wire me the harness. I guess it's just a standalone harness. He's listed all the connectors I need to get the engine going. Stuck on what to do with the C207. I can't find an exact match of wiring pinouts theres a couple of colours wrong, but I'm mainly not sure of what I'm supposed to connect these wires to. All the wires the harness builder lists for me to connect are elsewhere, mainly off the C100. Ecm fuses, fuel pump fan relays are all on a fuse block he wired into the harness, and aside from speedo input (not much help to me anyways being an 1987 V6 cable driven)/I don't see anything I need to connect... Or am I wrong? Any help is Appreciated
I had a guy wire me the harness. I guess it's just a standalone harness. He's listed all the connectors I need to get the engine going. Stuck on what to do with the C207. I can't find an exact match of wiring pinouts theres a couple of colours wrong, but I'm mainly not sure of what I'm supposed to connect these wires to. All the wires the harness builder lists for me to connect are elsewhere, mainly off the C100. Ecm fuses, fuel pump fan relays are all on a fuse block he wired into the harness, and aside from speedo input (not much help to me anyways being an 1987 V6 cable driven)/I don't see anything I need to connect... Or am I wrong? Any help is Appreciated
#184
COTM Editor
iTrader: (22)
Join Date: Mar 2001
Posts: 9,892
Likes: 0
Received 1,855 Likes
on
1,270 Posts
Car: '89 Firebird
Engine: 7.0L
Transmission: T56
Re: How to prep a 3rd gen harness
For the most part, people use C207 as a place to pick up switched B+ power, and feed in the speed signal for speedometer. If you already took care of those things then you are done.
#185
COTM Editor
iTrader: (22)
Join Date: Mar 2001
Posts: 9,892
Likes: 0
Received 1,855 Likes
on
1,270 Posts
Car: '89 Firebird
Engine: 7.0L
Transmission: T56
Re: How to prep a 3rd gen harness
You can also use C207 to operate the "Service Engine Soon" light as a substitute for the MIL lamp that would have been in a 4th gen. Connect pin R46 of the LS1 PCM to the correct wire at C207 and the PCM will run the SES light. In my case (1989 Firebird) that is C207 pin C.
If you are unsure which is the correct wire then use a multi-meter to do a continuity check from the ground side of the SES light bulb in the gauge pod to the connections at C207. The one that has continuity is your winner.
If you are unsure which is the correct wire then use a multi-meter to do a continuity check from the ground side of the SES light bulb in the gauge pod to the connections at C207. The one that has continuity is your winner.
#186
Junior Member
Join Date: Mar 2016
Location: Ontario, Canada
Posts: 11
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1987 Camaro
Engine: 4.8L LS
Transmission: 4l60E w/Shift Kit
Axle/Gears: 4th Gen Rear, 3.73 Posi
Re: How to prep a 3rd gen harness
Thanks. I found out my fuel pump wire runs through there as well, so the Mil, Fuel Pump and keyed power for my OBD II port should be it. MY speedo is not needed at the moment so Ill leave that out. Thanks for the continuity idea for finding wires, never thought pf that.
Another point, would I be correct to say the PNK/BLK wire out of c100 is a keyed power too?
Another point, would I be correct to say the PNK/BLK wire out of c100 is a keyed power too?
#190
Member
Re: How to prep a 3rd gen harness
After years as a member of e-mail list server type sharing it took me a while to get the hang of forums. Old habits can take some time to die off...
M
M
#191
Re: How to prep a 3rd gen harness
I have a question about this.. What if you swapped in an LS but kept the 700r4 and the PCM was reprogrammed to accept 8k PPM? How could you retain the usage of your original speedometer? My trans am was a '87 TPI electric speedo.
#192
Junior Member
Join Date: Dec 2016
Location: Windsor Ontario Canada
Posts: 15
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1990 Chevy Camaro RS 5.0l tpi
Engine: 305TPI originally TBI
Transmission: 5spd
Re: How to prep a 3rd gen harness
anyone still do these harnesses? Its gona take me 8 years to do it myself.
#193
Junior Member
Join Date: Jan 2015
Location: Tampa Bay
Posts: 51
Likes: 0
Received 1 Like
on
1 Post
Car: 85 Trans Am
Engine: LT1 (in process)
Transmission: T-5
Axle/Gears: 9 bolt 3.27
Re: How to prep a 3rd gen harness
Once you start removing the unnecessary wires it starts looking much less scary. I tackled mine in like 30 min bites, focusing on just a couple wires each time. . . Kept me from getting overwhelmed and frustrated.
If you're trying do the swap on a budget then it's worth it to do yourself.
#194
Re: How to prep a 3rd gen harness
I am a new member to group and have a few questions. I have a 91 z28 original TPI car i am putting an LS in to.The guy i sold the motor to wanted the engine harness also . So i unplugged the C100 connector from firewall and from computer . Now of course i have no power on anything . What pins are needed on the connector on firewall to power lights and interior? I separated the headlight harness from the engine harness so it is still plugged in.Thanks
#196
Re: How to prep a 3rd gen harness
This photobucket thing is killing me. Anyone know another place that has this info or is someone working to straighten this out. I'm about to start an ls swap and all the help I can get.
#197
Junior Member
Join Date: Apr 2016
Location: New Zealand
Posts: 14
Likes: 0
Received 0 Likes
on
0 Posts
Car: 1986 IROC Z28
Engine: LS 5.3
Transmission: T5
Re: How to prep a 3rd gen harness
The C100 plug has the main power from the battery going through it into the car , you have given it away with the motor , you should be able to pick it up with a wire diagram as I did . its pretty straight forward
#198
Member
iTrader: (1)
Re: How to prep a 3rd gen harness
I've searched and read but still a little confused. On my 86 Camaro C100, do my 2 red wires and purple go to the starter, or just purple. Red wires to a distribution block maybe, but is that needed? Also read where pink wire isn't used on some swaps, so am I using it? Lastly my C221 has fuses for Inj1 and Inj2, so that's what I tie into my pinks from injectors correct. My battery is in the back. Thanks.
#199
Junior Member
iTrader: (1)
Join Date: Jul 2013
Location: Newburgh, IN
Posts: 77
Likes: 0
Received 0 Likes
on
0 Posts
Car: 89 Formula WS6
Engine: LQ4 h/c/i
Transmission: TH-FO-HUNNIT
Axle/Gears: 3.73
Re: How to prep a 3rd gen harness
I've searched and read but still a little confused. On my 86 Camaro C100, do my 2 red wires and purple go to the starter, or just purple. Red wires to a distribution block maybe, but is that needed? Also read where pink wire isn't used on some swaps, so am I using it? Lastly my C221 has fuses for Inj1 and Inj2, so that's what I tie into my pinks from injectors correct. My battery is in the back. Thanks.
