Old 11-06-2011, 11:04 AM   #1
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Sonoma sbc turbo build

hey guys, names jesse.. been on s10forum and whatnot for a long long time.. decided to come on here since you guys are all gods of the small blocks and what needs to be done.. Anyways a overview of what i got, its a 2001 sonoma on full airsuspention, custom interior and bed, all that jazz. Last year i decided to pull the 2.2 out and build my first 350 and stick it in. Block is a 78 c10 2-bolt, installed a thumper cam and some vortech heads, performer intake and a 750 edelbrock carb. Put down 330hp and 375tq on the dyno last winter. Well this year its time for a big change. I bought a 78 4-bolt block for 50$ from a guy at work and gonna stick that in, but will also be adding a turbo to this one. Was thinking about doing a twin but would run into major clearance issues on the drivers side so i will be doing a single. I will be purchasing the turbo kit/headers/wastegate hopefully next friday and i will be going from there and peiceing everything else together. Also got a few other plans i will be doing over winter to.. but as for now the list goes and i kno much more will be needed:
- LSD rear end
- holly 750 carb converted blowthrew
- Single turbo
- Line-lock on breaks
- Electronic cut-out

and heres some of the truck:


http://i817.photobucket.com/albums/zz100/pearl01chevy/Sonoma/Interior/SL374906.jpg[/IMG]




And heres how she sits currently, taking a/c box out and putting heater only in:


radiator mounted inside support:


LSD picked up for 80bucks w/axels


Still thinking about going w/this to:
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-07-2011, 11:01 AM   #2
Senior Member

89fbrestor's Avatar

Join Date: Mar 2007
Location: midland michigan
Posts: 802
Car: currently 91 camaro
Engine: soon to be 350 turbo
Transmission: soon to be 4l80e
Axle/Gears: 99 ss rear end with richmond 4:11's

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

should be an interesting ride.
89fbrestor is offline vBGarage Page   Reply With Quote
Old 11-07-2011, 11:32 AM   #3
Senior Member

Join Date: May 2010
Location: Brunswick, OH; Las Vegas, NV
Posts: 715
Car: '86 Grand National
Engine: LC2
Transmission: 2004R
Axle/Gears: 3.42

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

did your other truck you sold ever get the turbo installed, and running?
34blazer is offline vBGarage Page   Reply With Quote
Old 11-07-2011, 10:22 PM   #4
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

the turbo was installed and had all the exhaust piping done and then i sold it. So sadly no i never got to see it run. Always wondered how it woulda been though.. And having said that it makes me confident to complete this build!
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-16-2011, 10:14 PM   #5
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Hopefully this post gets some much needed attention in the threads!! hah
Starting out pretty much got the radiator/support done, still need to throw some filler on there and do a final paint but im happy with the turnout! its nice and flush so ill have more space in the engine compartment.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
and FINALLY my turbo kit came!! Been a long week and half wait but im sooo happy its here! Turbo is alot bigger then i expected
Click the image to open in full size.
Click the image to open in full size.
The wastegate
Click the image to open in full size.
And the headers/crossover pipe, i can only use the passenger header for clearance issues.. and btw i didnt even have this kit in my garage for a hour before i started cutting it up to fit haah
Click the image to open in full size.
Click the image to open in full size.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-16-2011, 10:15 PM   #6
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Click the image to open in full size.
And heres another clearance issue which is not alllowing the turbo to sit flush on the header plate
Click the image to open in full size.
And the wastegate tube needs to be moved up i say 2inchs and ill be good with that
Click the image to open in full size.
And heres the money shots!
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
And lastly i sent my 4bolt block yesturday to the machine shop!
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-16-2011, 10:28 PM   #7
Senior Member

Join Date: May 2010
Location: Brunswick, OH; Las Vegas, NV
Posts: 715
Car: '86 Grand National
Engine: LC2
Transmission: 2004R
Axle/Gears: 3.42

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

what turbo is that? nice pics!
34blazer is offline vBGarage Page   Reply With Quote
Old 11-16-2011, 10:30 PM   #8
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

brand or size?? Gt45 Compressor:
Trim: 69
A/R: .66
Inducer: 68.7
Exducer: 97.8
Turbine:Trim: 92
A/R: 1.05
Inducer: 87.4
Exducer: 77
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 01:03 AM   #9
Supreme Member

Join Date: Jan 2002
Location: garage
Posts: 4,100
Engine: 305ci DIY twin T3 50 trim
Transmission: 199x DIY 4L60E

Classifieds Rating: (1)

Re: Sonoma sbc turbo build

Quote:
Originally Posted by 34blazer View Post
what turbo is that?
It is known as the China Ebay GT45 knock off of the Master Power GT45.
The exhaust is the China Ebay knock off of the SSAC header.
junkcltr is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 07:09 AM   #10
Senior Member

Join Date: May 2010
Location: Brunswick, OH; Las Vegas, NV
Posts: 715
Car: '86 Grand National
Engine: LC2
Transmission: 2004R
Axle/Gears: 3.42

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

i figured it was a chinese turbo since i didnt see any markings. was just wondering the size, looks huge lol.
34blazer is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 07:47 AM   #11
Senior Member

calebzman's Avatar

Join Date: Oct 2004
Location: Cleveland, Ohio
Posts: 797
Car: '85 TA
Engine: 350 turbo
Transmission: T56
Axle/Gears: 3.70 posi 9bolt

Classifieds Rating: (3)
Re: Sonoma sbc turbo build

What are you going to do about the turbo hitting the alternator? It looks like you'll have plenty of room on the upper driver side to relocate it there?
__________________
'85 TA, 350 w/ forged internals, First TPI, Procomp 190cc heads, Crane 212/218 cam, 58mm TB, 60lb injectors, Holley Commander 950, LC-1, MSD 6A, turbo & intercooled

my cardomain
calebzman is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 10:34 AM   #12
Senior Member

Join Date: Feb 2005
Location: meridian, idaho
Posts: 570
Car: 92 1500p\u 2wd
Engine: 91 z28 tpi 355
Transmission: 91 700r4

Classifieds Rating: (2)
Re: Sonoma sbc turbo build

subed nice truck!
355tpipickup is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 05:13 PM   #13
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

originally i wanted to do a twin turbo setup. But with the headers thats sold for the twin kit the turbo would be setting where the mastercylinder is for the breaks. And i was seaching around and found a 1/4 and 1/2" spacer so i can space out the turbo if i need to, but im about to run down and move it and see if theres a difference. Also i kno ill need to wrap that turbo

but anyways.. i called the machine shop today and talked to them. They said the 4bolt block would need a bore so i said screw it and doing 30over. So now ill have a 355.. And the other question i got for now is this is the cam i got in the truck currently, would this be alright to run with my turbo? or should i look elseware
Click the image to open in full size.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 06:05 PM   #14
Senior Member

Join Date: May 2010
Location: Brunswick, OH; Las Vegas, NV
Posts: 715
Car: '86 Grand National
Engine: LC2
Transmission: 2004R
Axle/Gears: 3.42

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

the LSA seems too narrow for a turbo. the overlap is 20* which also seems a little too much.
34blazer is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 07:18 PM   #15
Supreme Member

Join Date: Jan 2002
Location: garage
Posts: 4,100
Engine: 305ci DIY twin T3 50 trim
Transmission: 199x DIY 4L60E

Classifieds Rating: (1)

Re: Sonoma sbc turbo build

That looks like a supercharger/nitrous cam. I would look for something more turbo friendly.

Have you thought about using a smaller sized CS130 alternator that will put out as much amps as that 12SI alternator? I used the same header and had to make a low mount alternator setup to clear the 12SI and a Garrett T04E compressor with a smaller/lower .84 A/R turbine. The CS130 would have been a better choice.

That 69mm compressor wheel will work great on a 355ci.
junkcltr is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 07:26 PM   #16
Supreme Member

FSTFBDY's Avatar

Join Date: Jul 2000
Location: Boosted Land
Posts: 5,879
Car: 92 Vert
Engine: 383 LT1 w/ 78mm turbo
Transmission: T56
Axle/Gears: 9bolt 3.45

Classifieds Rating: (33)

Re: Sonoma sbc turbo build

Nice truck.. Should be a sweet ride when done.
Thats a BBSD knock off turbo setup. Was sold on ebay years ago also.
__________________


'92 vert 383 LT1 , T56 | OPTI Delete running MSD Pro Billet Distrib. | Callies crank & rods | JE Pistons | 78mm turbonetics turbo, Tial 50mm BOV , Tial 44mm waste gate| spohon adj. trq arm, cross member , etc..

Custom Billet Parts made to order. Powder Coating , Thermal & Ceramic Coatings. PM ME

Last edited by FSTFBDY; 11-17-2011 at 07:31 PM.
FSTFBDY is offline vBGarage Page   Reply With Quote
Old 11-17-2011, 09:13 PM   #17
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

ah thanks so much guys for the post..
I need a more powerful alternator as it is considering all the air compressors i run for the air suspention. That little stock alt is cutting it thats for sure.

And yea i got it off ebay.. i figured it was a good price for what i got, i knew i had to do modds to everything since there is no such thing for a kit to mount a turbo in a s10 with a sbc..

and 34blazer.. i honestly dont understand cams to much, can ya go more into details if its not to big of a deal thanks!

Another quick question. my buddy has this carb: http://www.summitracing.com/parts/HLY-65-3310/
he will sell it to me for 30 bucks, it will need a rebuild kit even though it was running on the truck when he got it "i seen it run". Will this be ok for boost? i know i have to do that whole conversion thing to so its a blow threw, but is this a good canadit? i currently have a edelbrock 1407 carb: http://www.summitracing.com/parts/EDL-1407/

Last edited by pearl01chevy; 11-17-2011 at 09:22 PM.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-18-2011, 07:45 AM   #18
Supreme Member

Street Lethal's Avatar

Join Date: Jul 2003
Location: New Jersey
Posts: 7,119
Car: 1990 GTA
Engine: 5.0L Turbo V8
Transmission: 700R4

Classifieds Rating: (12)

Re: Sonoma sbc turbo build

Quote:
Originally Posted by pearl01chevy
i honestly dont understand cams to much, can ya go more into details if its not to big of a deal thanks!
Reversion only has a negative effect w/superchargers, not turbo chargers. The cycling rate w/turbo's is high during boost, and even during idle speeds, any charge that escapes through overlap is being used to spin the turbine. It isn't necessarily wasted. Not so with superchargers of course, which is why boost pressure suffers with too much overlap because the boost escapes quench and heads straight to the exhaust. No turbine. Run the cam you have, it should work well for you...
__________________
'90 Trans Am GTA: Worked 305-TPI, Dynamic EFI's EBL-P4, T72 Turbo...

... stage II Buick TT V6 going in next.

'96 Chevy Corvette: Worked 350-LT1, FAST-XFI, w/D1SC Procharger...

... F2 Procharger going in next.
Street Lethal is offline vBGarage Page   Reply With Quote
Old 11-18-2011, 09:08 AM   #19
Supreme Member

Orr89RocZ's Avatar

Join Date: Sep 2003
Location: Pittsburgh PA
Posts: 19,528
Car: 89 Iroc-z
Engine: Twin Turbo 401
Transmission: TH400
Axle/Gears: 4th gen 12 bolt 3.42

Classifieds Rating: (20)

Send a message via AIM to Orr89RocZ
Re: Sonoma sbc turbo build

Vast majority of turbo cams out there do not look like that I still think there will be some reversion regardless if theres a turbo or not on the exhaust. Thats a big duration overlap event on a smaller motor. All cammed cars with decent overlap have reversion at idle and sometimes low engine speeds.

The better the design is for the turbo system, from headers to turbine sizing, generally see less and less back pressure. The closer you are to 1 to 1 ratio of intake boost/exhaust backpressure, or even to the point of LESS exhaust backpressure vs intake boost pressure, the more closely the Cam can match a n/a type motor spec. I wouldnt use that cam, but it may "work" it just wont work as well as it could.

I doubt that header design will show less back pressure vs boost pressure so the overlap on the cam should be cut down.
__________________
1989 Twin Turbo IROC-Z
"Twin Turbo 401 Buildup Pics "
Photobucket 401 Twin Turbo
1009 whp / 844 wtq 24.5 psi pump gas only
Orr89RocZ is offline vBGarage Page   Reply With Quote
Old 11-18-2011, 09:27 AM   #20
Supreme Member

Street Lethal's Avatar

Join Date: Jul 2003
Location: New Jersey
Posts: 7,119
Car: 1990 GTA
Engine: 5.0L Turbo V8
Transmission: 700R4

Classifieds Rating: (12)

Re: Sonoma sbc turbo build

The beauty w/reversion in his turbo application is that he will get the added benefit of even more higher RPM perfomance to be used w/that GT45 turbo. Common flat spot's w/reversion in naturally aspirated applications will not apply here, and the charge is literally instantaneous, even at idle speeds. The turbine cannot differentiate between a burned mixture, or an unburned mixture, it only knows to move when being pressurized to do so, so in the end all pressure is being forced through the exhaust valve, regardless. I for one even noticed a decrease in EGT when switching from a 116-LSA down to a 110-LSA, more than likely due to the slight amount of unburned and colder air entering into the turbine exhaust housing...
__________________
'90 Trans Am GTA: Worked 305-TPI, Dynamic EFI's EBL-P4, T72 Turbo...

... stage II Buick TT V6 going in next.

'96 Chevy Corvette: Worked 350-LT1, FAST-XFI, w/D1SC Procharger...

... F2 Procharger going in next.
Street Lethal is offline vBGarage Page   Reply With Quote
Old 11-18-2011, 09:42 AM   #21
Supreme Member

Orr89RocZ's Avatar

Join Date: Sep 2003
Location: Pittsburgh PA
Posts: 19,528
Car: 89 Iroc-z
Engine: Twin Turbo 401
Transmission: TH400
Axle/Gears: 4th gen 12 bolt 3.42

Classifieds Rating: (20)

Send a message via AIM to Orr89RocZ
Re: Sonoma sbc turbo build

EGT would drop due to unburned mixture. Did that not affect turbine performance? Heat is a key element in getting spool but so is exhaust pressure pulse energy which is related to the heat.

I've only seen one other setup that used a tight 108 lsa cam and it runs hard. Blown385 I think his name was on TTF.com. Has the turbo sonoma or s10? Low 9 second almost high 8 second ride then? It was a tighter duration split cam, but tight LSA.
__________________
1989 Twin Turbo IROC-Z
"Twin Turbo 401 Buildup Pics "
Photobucket 401 Twin Turbo
1009 whp / 844 wtq 24.5 psi pump gas only
Orr89RocZ is offline vBGarage Page   Reply With Quote
Old 11-18-2011, 10:14 AM   #22
Supreme Member

Street Lethal's Avatar

Join Date: Jul 2003
Location: New Jersey
Posts: 7,119
Car: 1990 GTA
Engine: 5.0L Turbo V8
Transmission: 700R4

Classifieds Rating: (12)

Re: Sonoma sbc turbo build

Quote:
Originally Posted by Orr89RocZ
EGT would drop due to unburned mixture. Did that not affect turbine performance? Heat is a key element in getting spool but so is exhaust pressure pulse energy which is related to the heat...
The drop was not significant enough, nor substantial enough to negatively effect the efficiency of the turbo, but just enough to see that difference. The turbo is going to get hot, regardless. Not to mention, I would much rather see a slight decrease in EGT's to help maximize a more denser and oxygenated intake charge, as opposed to keeping the turbo at it's hottest point, then resting on the hopes that the intercooler does it's job of lowering air temperature, even on a brutal summer day. It is essentially a healthy compromise between the two. Could always run anti-lag/two step as well w/that cam and turbo...
__________________
'90 Trans Am GTA: Worked 305-TPI, Dynamic EFI's EBL-P4, T72 Turbo...

... stage II Buick TT V6 going in next.

'96 Chevy Corvette: Worked 350-LT1, FAST-XFI, w/D1SC Procharger...

... F2 Procharger going in next.
Street Lethal is offline vBGarage Page   Reply With Quote
Old 11-20-2011, 12:45 PM   #23
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

well for ***** and giggles decided to threw my old hood on and check to see how much i'd have to cut the hood up for the turbo, i sput the one side of the turbo so it wasnt pointing up anymore and it helped out but.. boy was i suprised.. i got a crapload of room between the hood and the turbo so im extremely happy with that. I even added a temporary 1/4" spacer between the turbo and the header to get it up off the valve cover and alternator.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-21-2011, 06:19 AM   #24
Senior Member

Join Date: Nov 2003
Location: upstate new york
Posts: 315
Car: 91 camaro rs
Engine: 355, blowthru, 78mm turbo
Transmission: th350, art carr converter
Axle/Gears: stock 7.5, 3.23s, minispool

Classifieds Rating: (0)
Send a message via AIM to 5literTPIterror
Re: Sonoma sbc turbo build

not gonna get the forum too off topic, but heres a pic of mine, lq4 6.0 liter, 4l80e, 12 bolt, tc78 turbo.
second pass 10.82 at 128.5, 10 psi.

also on a log manifold,
Attached Images
File Type: jpg 11.jpg (130.9 KB, 60 views)
File Type: jpg 315096_263091143733294_100000972318538_747824_180341840_n.jpg (109.5 KB, 34 views)
5literTPIterror is offline vBGarage Page   Reply With Quote
Old 11-21-2011, 10:04 AM   #25
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

holy **** lol, that thing is sweet! bet it was fun getting all that to fit.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-21-2011, 03:31 PM   #26
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

this motor is easier and easier everytime i pull it.. Got it out in about 2 hours even with a poop break
Click the image to open in full size.
Click the image to open in full size.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-21-2011, 03:58 PM   #27
Senior Member

Join Date: Nov 2003
Location: upstate new york
Posts: 315
Car: 91 camaro rs
Engine: 355, blowthru, 78mm turbo
Transmission: th350, art carr converter
Axle/Gears: stock 7.5, 3.23s, minispool

Classifieds Rating: (0)
Send a message via AIM to 5literTPIterror
Re: Sonoma sbc turbo build

mines a major pain to pull.. cant pull motor / trans seperate, have to pull em together ( 4l80e is so huge in the trans tunnel..) which means i have to take off radiator, core support etc.. and come straight out the front with it...
5literTPIterror is offline vBGarage Page   Reply With Quote
Old 11-21-2011, 04:05 PM   #28
Senior Member

Join Date: Nov 2003
Location: upstate new york
Posts: 315
Car: 91 camaro rs
Engine: 355, blowthru, 78mm turbo
Transmission: th350, art carr converter
Axle/Gears: stock 7.5, 3.23s, minispool

Classifieds Rating: (0)
Send a message via AIM to 5literTPIterror
Re: Sonoma sbc turbo build

im gonna push it in the spring with race gas and cal tracs and more boost ( maybe bigger turbo..) and see what i can squeeze outta this junk yard motor
5literTPIterror is offline vBGarage Page   Reply With Quote
Old 11-21-2011, 06:56 PM   #29
Junior Member

91kbell's Avatar

Join Date: Nov 2008
Posts: 38

Classifieds Rating: (1)
Re: Sonoma sbc turbo build

Do you have a stall in the truck now?
91kbell is offline vBGarage Page   Reply With Quote
Old 11-22-2011, 07:21 PM   #30
Senior Member

Join Date: Nov 2003
Location: upstate new york
Posts: 315
Car: 91 camaro rs
Engine: 355, blowthru, 78mm turbo
Transmission: th350, art carr converter
Axle/Gears: stock 7.5, 3.23s, minispool

Classifieds Rating: (0)
Send a message via AIM to 5literTPIterror
Re: Sonoma sbc turbo build

Do you have a stall in the truck now?

^ not sure if this was to me or the OP, i have a 3500 and it drives like totally stock, i will be loosening it to around 4000 for next year..
5literTPIterror is offline vBGarage Page   Reply With Quote
Old 11-22-2011, 09:11 PM   #31
Junior Member

91kbell's Avatar

Join Date: Nov 2008
Posts: 38

Classifieds Rating: (1)
Re: Sonoma sbc turbo build

Op, Depending on it's purpose I'd think that a street driven turbo truck would benefit from a low stall.
91kbell is offline vBGarage Page   Reply With Quote
Old 11-23-2011, 03:51 PM   #32
Senior Member

Join Date: Feb 2005
Location: meridian, idaho
Posts: 570
Car: 92 1500p\u 2wd
Engine: 91 z28 tpi 355
Transmission: 91 700r4

Classifieds Rating: (2)
Re: Sonoma sbc turbo build

Now i want to turbo my truck! looks fun and fast for sure but need more money haha
355tpipickup is offline vBGarage Page   Reply With Quote
Old 11-24-2011, 12:38 PM   #33
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

think its a stock stall whatever that is.. i kno he told me but i just cant remember for the life of me.. and thanks 355pipickup
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-26-2011, 09:36 AM   #34
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Motor is stripped down and ready to sell
Click the image to open in full size.
Just curious why would the cam look like this on spots?
Click the image to open in full size.
Also im a bit weary of this timing gear after seeing this..
Click the image to open in full size.
Also instead of drilling and tapping a hole in the oil pan for a return like, couldnt i just drill and tap into this plate??
Click the image to open in full size.
and the wheel wells are out, bout to start the long process of getting that frame cleaned up
Click the image to open in full size.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 11-27-2011, 09:18 AM   #35
Senior Member

calebzman's Avatar

Join Date: Oct 2004
Location: Cleveland, Ohio
Posts: 797
Car: '85 TA
Engine: 350 turbo
Transmission: T56
Axle/Gears: 3.70 posi 9bolt

Classifieds Rating: (3)
Re: Sonoma sbc turbo build

For your oil return question, you can add a fitting in the fuel pump block off plate and drain the oil there. Here's mine:

Click the image to open in full size.
calebzman is offline vBGarage Page   Reply With Quote
Old 12-11-2011, 05:34 PM   #36
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Finally finally got my block back, some info on it: bored .30 over, magnafluxed, cleaned, hoaned, new cam bearings installed and new freeze plugs installed.. man oh man not a nice bill but in the end it was so worth it. she sooo pretty!!
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
Click the image to open in full size.
And this is gonna get outta control quick since im so picky.. frames getting por-15
Click the image to open in full size.
Click the image to open in full size.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 12-11-2011, 08:58 PM   #37
Junior Member

Join Date: Jun 2009
Posts: 73
Car: 1992 camaro RS
Engine: 5.3 lsx
Transmission: 4l60, soon to be t-56
Axle/Gears: 3.23

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Man your going to need to put a turbo on the other side also to balance the truck out haha. Sweet build.
zayne0 is offline vBGarage Page   Reply With Quote
Old 12-13-2011, 05:04 PM   #38
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

alright back to motor questions.. getting ready to buy the pistons/rods.. what would be best for my setup?? I was looking at these for pistons :http://www.summitracing.com/parts/UEM-KB171-020/

and what about rods?? my stock rods wont hold up correct?? looking for some opionions on parts that wont kill my wallet.
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 12-13-2011, 05:41 PM   #39
Supreme Member

Orr89RocZ's Avatar

Join Date: Sep 2003
Location: Pittsburgh PA
Posts: 19,528
Car: 89 Iroc-z
Engine: Twin Turbo 401
Transmission: TH400
Axle/Gears: 4th gen 12 bolt 3.42

Classifieds Rating: (20)

Send a message via AIM to Orr89RocZ
Re: Sonoma sbc turbo build

I'd rather see forged pistons and h-beam rods with good bolts for a turbo car but do what you can with your budget. Pistons can live if the tune is right. Spend money on the rods/rod bolts to be most safe.

Not sure what heads you were going to use or if you are keeping this a 355 or going 383 but flat tops with a 355 and 64cc head is low 10's to 1 compression. With a 383 thats 11 to 1. Too high for boost. I like 9-9.5 to 1 with aluminum heads. Would need a small dish piston.
__________________
1989 Twin Turbo IROC-Z
"Twin Turbo 401 Buildup Pics "
Photobucket 401 Twin Turbo
1009 whp / 844 wtq 24.5 psi pump gas only
Orr89RocZ is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 06:53 AM   #40
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

for now i plan on keeping the vortech heads, going to put roller rockers on them also and possibly change the springs.. and yes i do plan on keeping it a 355. and thanks for that tip.. back to searching!
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 07:00 AM   #41
Supreme Member

Orr89RocZ's Avatar

Join Date: Sep 2003
Location: Pittsburgh PA
Posts: 19,528
Car: 89 Iroc-z
Engine: Twin Turbo 401
Transmission: TH400
Axle/Gears: 4th gen 12 bolt 3.42

Classifieds Rating: (20)

Send a message via AIM to Orr89RocZ
Re: Sonoma sbc turbo build

Iron heads, keep compression down 8.5 to 1 or so
__________________
1989 Twin Turbo IROC-Z
"Twin Turbo 401 Buildup Pics "
Photobucket 401 Twin Turbo
1009 whp / 844 wtq 24.5 psi pump gas only
Orr89RocZ is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 10:38 AM   #42
Senior Member

Join Date: Jul 2005
Posts: 969

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Avoid the Kieth Blacks. The ring lands are a lot higher up on them than a traditional piston. This makes it a weaker land, as well as making it more likely the rings will but. If you do use them I would strongly advise looking at their web site as I do believe they have a modified gap chart. I suspect that's a reason why people have issues with them.

Personally I would use something like this:

http://www.summitracing.com/parts/STL-H580P30/

Yeah they are heavier but at the same time there are a few people using these with good results in the Turbo Buick community.
Drac0nic is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 12:34 PM   #43
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

those pistons are redicously cheap price wise, thought i'd need forged?? or will those be alright?
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 12:51 PM   #44
Senior Member

89fbrestor's Avatar

Join Date: Mar 2007
Location: midland michigan
Posts: 802
Car: currently 91 camaro
Engine: soon to be 350 turbo
Transmission: soon to be 4l80e
Axle/Gears: 99 ss rear end with richmond 4:11's

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

Quote:
Originally Posted by pearl01chevy View Post
those pistons are redicously cheap price wise, thought i'd need forged?? or will those be alright?

umm me to.. anxious to hear the answer to this one. i was going to spend $500 on pistons for my build but if i can use these then pshh life is good lol

Last edited by 89fbrestor; 12-14-2011 at 12:58 PM.
89fbrestor is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 01:43 PM   #45
Supreme Member

Orr89RocZ's Avatar

Join Date: Sep 2003
Location: Pittsburgh PA
Posts: 19,528
Car: 89 Iroc-z
Engine: Twin Turbo 401
Transmission: TH400
Axle/Gears: 4th gen 12 bolt 3.42

Classifieds Rating: (20)

Send a message via AIM to Orr89RocZ
Re: Sonoma sbc turbo build

They may live if you dont push them hard enough and dont run the chamber so hot. But if you are doing this right the first time, it makes sense to atleast have forged pistons. They are much more forgiving than hyper's
__________________
1989 Twin Turbo IROC-Z
"Twin Turbo 401 Buildup Pics "
Photobucket 401 Twin Turbo
1009 whp / 844 wtq 24.5 psi pump gas only
Orr89RocZ is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 01:47 PM   #46
Senior Member

89fbrestor's Avatar

Join Date: Mar 2007
Location: midland michigan
Posts: 802
Car: currently 91 camaro
Engine: soon to be 350 turbo
Transmission: soon to be 4l80e
Axle/Gears: 99 ss rear end with richmond 4:11's

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

i plan on pushing mine so I'll go forged bummer got excited for nothing
89fbrestor is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 05:09 PM   #47
Junior Member

Join Date: Nov 2011
Posts: 37

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

hahaha same here.. but how hard are you ACTUALLY pushing yours?? mines only a weekend driver and maybe the strip here and there.. just something to play around with, nothing serious.. would this pass for the pistons posted above?? also any suggestions on rods??
pearl01chevy is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 05:26 PM   #48
Supreme Member

Orr89RocZ's Avatar

Join Date: Sep 2003
Location: Pittsburgh PA
Posts: 19,528
Car: 89 Iroc-z
Engine: Twin Turbo 401
Transmission: TH400
Axle/Gears: 4th gen 12 bolt 3.42

Classifieds Rating: (20)

Send a message via AIM to Orr89RocZ
Re: Sonoma sbc turbo build

Alot of guys have boosted stockish motors with hyper pistons just fine. Its worth a shot if you are comfortable with tuning and take it easy at first. Keep it safe.
Orr89RocZ is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 08:34 PM   #49
Senior Member

Join Date: Jul 2005
Posts: 969

Classifieds Rating: (0)
Re: Sonoma sbc turbo build

No not saying that they are the absolute best but I would use em way before the kbs. My buddy went mid 11s wit a buick v6 on the trw hypers though. 27lbs boost and he did about 75 of spray too. Keeps eating cams but the pistons are fine. Ton of street miles and track time. Open the gaps up too, that is probably a big part of it as well.
Drac0nic is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 08:55 PM   #50
Supreme Member

project89's Avatar

Join Date: Apr 2008
Location: Utah
Posts: 8,042
Car: 89 RS 89 iroc 87 firebird
Engine: 3.1 Turbo/ 355 twin turbo
Transmission: a4 w/ 4500 stall/ a4 / t5
Axle/Gears: strange s60 /w 3:42's

Classifieds Rating: (1)
Re: Sonoma sbc turbo build

dont use that cam, it apears to be a comp cams "thumper" cam, they use lots of overlap to get that rough race car type idle sound.stick with something in the 224/224/ 232/232 duration range
__________________
Car 1 1989 Iroc-z 353SBC 200cc HEADS 224/224 CAM HSR TWIN GT3582 TURBOS 1,000+HP OR BUST AKA THE DAILY DRIVER
Car2 1989 RS 3.1L v6, KB pistons, delta cam,ported heads/intake, custom stainless turbo headers, garrett 60-1 turbo 380+HP@9PSI
Car3 1988 Firebird. stock bottom end, ported heads, delta cam, custom intake, gm 4-71 roots blower HP???? TBD


project89 is offline vBGarage Page   Reply With Quote
Old 12-14-2011, 08:55 PM
ThirdGen
1992 Camaro




Paid Advertisement


Reply

Go Back   Third Generation F-Body Message Boards > Tech Boards > Power Adders

Tags
build, crossover, ebay, gas, gen, gt45, ideas, kit, pump, sbc, single, thirdgen, timing, truck, turbo
Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off




1982 Camaro '82 || 1983 Camaro '83 || 1984 Camaro '84 || 1985 Camaro '85 || 1986 Camaro '86 || 1987 Camaro '87 || 1988 Camaro '88 || 1989 Camaro '89 || 1990 Camaro '90 || 1991 Camaro '91 || 1992 Camaro '92


All times are GMT -5. The time now is 06:15 PM.


Powered by vBulletin® Version 3.7.5
Copyright ©2000 - 2014, Jelsoft Enterprises Ltd.
Search Engine Friendly URLs by vBSEO 3.5.2
All content copyright 1997 - 2014 ThirdGen.org. All rights reserved. No part of this website may be reproduced without the expressed, documented, and written consent of ThirdGen.org's Administrators.

Emails & Contact Details
