ok i installed the solenoids and ran all the wires according to this schematic it was working ok in the garage but when i pulled the car out of the garage the remote control box started blowing fuses everytime i try to open the door with the remote.. if anyone could maybe shown me a better diagram of how its supposed to be wired from someone whos done this before that would be great..


also i did check all the +wires to make sure none of them are grounding out



bump


need help fast
think maybe my relays are wired wrong?



bump


anyone?



Check the relays, definitely. Terminals 85 and 86 are the "control" terminals. You apply power to them to trigger the relay.
30 and 87 are the "load" terminals. The relay connects 30 and 87 when you apply power to the "control" terminals.

You can checkthe "load" circuit in the following way: on each relay, pull the wire off terminal 30 and touch it to terminal 87. That will complete the "load" circuit and the door should open. It will make a small spark, that's normal.

If this test blows your fuse, you might want to check if you have the right size fuse for the load or if the circuit is wired correctly.

Also, you can leave the terminal 30 disconnected and try pressing the remote button. The door should NOT pop. The relay should click. If it blows the fuse, it's the "control" circuit that's wrong.

Hope this helps.
Let us know what you find.
Lou



ok i figured out my problem i didn't have the ground wire on the same terminals on both relays... now i think my control box is forgetting the remotes lol i got it working pretty consistently so far gonna check see if it forgot the remote again in the morning...


BTW thanx for the info BigBabyLou helped alot



I found this... A little late, but you may want to keep it around.



wow thats exactly the same as my instructions just doesn't look like its a copy of a copy about 50 times over... lol i couldn't make out the number on the relays in my instructions lol that from your kit?



Nope, I did a search for the filename that I read on the bottom of the pic you attached in your first post



dang i must have been having a duh moment to not think of that lol
