Newbie Cowl Tag Codes?

Old 11-04-2008, 09:55 PM
  #1
Junior Member
Thread Starter

Join Date: Nov 2008
Posts: 38
Newbie Cowl Tag Codes?

I have an 83 T-Top Z28 w/ Cross-Fire 305 and Cowl fiberglass Hood. Could you help with mine?

D 04A 1FP87 L 132927
22D 11L 11U W
AF9 CG1
D B S 319481

Thank you so much.
dford is offline
Old 11-05-2008, 09:39 PM
  #2
Moderator

okfoz's Avatar

Join Date: Mar 2001
Location: Doghouse ∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑ Car: 1989 Formula 350 Vert Engine: 350 L98 Transmission: 700R4 Axle/Gears: B&W 3.27
Posts: 13,668
Car: 87 Formula T-Top, 87 Formula HT
Engine: 5.1L TPI, 5.0L TPI
Transmission: 700R4, M5
Axle/Gears: Sag 3.73, B&W 3.45
Re: Newbie Cowl Tag Codes?

AF9 should be AR9

22D is the interior color... not really sure I want to say Blue? and I suspect the Deluxe Cloth interior.
11L & 11U are Exterior colors The W indicates Waterbase or Waterborn Paint. I do not have the info in frot of me but I think 11 is White...

John
okfoz is offline
Old 11-06-2008, 12:36 PM
  #3
Supreme Member
iTrader: (2)

coolram62's Avatar

Join Date: Dec 2005
Location: Beaufort South Carolina
Posts: 1,739
Car: 1983 Camaro Z/28
Engine: LU5 305 CFI
Transmission: 700R4
Axle/Gears: J65/G80/G92-3.23
Re: Newbie Cowl Tag Codes?

John your correct the code 11 is white and water base (Van Nuys build). Also the 22D is dark royal blue custom cloth interior with L/S seats. That has me puzzled about the seat code as it would AQ9 then wouldn't it? And the CG1 should be CC1 if she is a factory T-Top car.
coolram62 is offline
Old 11-06-2008, 02:33 PM
  #4
Moderator

okfoz's Avatar

Join Date: Mar 2001
Location: Doghouse ∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑ Car: 1989 Formula 350 Vert Engine: 350 L98 Transmission: 700R4 Axle/Gears: B&W 3.27
Posts: 13,668
Car: 87 Formula T-Top, 87 Formula HT
Engine: 5.1L TPI, 5.0L TPI
Transmission: 700R4, M5
Axle/Gears: Sag 3.73, B&W 3.45
Re: Newbie Cowl Tag Codes?

Originally Posted by dford View Post
I have an 83 T-Top Z28 w/ Cross-Fire 305 and Cowl fiberglass Hood. Could you help with mine?

D 04A 1FP87 L 132927
D = 1983
04A = BUILD DATE April (04), First Week (A)
1 = Chevrolet
F = "F-Body"
P = Camaro
87 = 2 Door Coupe
L = Van Nuys CA - Plant of Manufacture
1 = Chevrolet
32927 = Build Sequence
Originally Posted by dford View Post
22D 11L 11U W
22D = (22) Blue Interior (D) "Deluxe Seats"
11L = (11) White (L) Lower
11U = (11) White (U) Upper
W = Waterbase Paint
Originally Posted by dford View Post
AF9 CG1
AR9 = Bucket Reclining Back
AQ9 = AR9 P/Seat & high Performance Bucket D/Seat
CG1 = Fleet Incentive, Consumer Products (-Trk CKGST)
CC1 = T-tops (More likely)
Originally Posted by dford View Post
D B S 319481
Not sure what the last line is, I have seen it before but I forget and I cannot find it in my books... Someone here knows...

Originally Posted by dford View Post

Thank you so much.
No Prob

John

Last edited by okfoz; 11-06-2008 at 02:38 PM.
okfoz is offline
Old 11-06-2008, 07:01 PM
  #5
Supreme Member
iTrader: (2)

coolram62's Avatar

Join Date: Dec 2005
Location: Beaufort South Carolina
Posts: 1,739
Car: 1983 Camaro Z/28
Engine: LU5 305 CFI
Transmission: 700R4
Axle/Gears: J65/G80/G92-3.23
Re: Newbie Cowl Tag Codes?

Dford and I have exchanged a couple PM's on the trim tag on his '83. The last line (D B S 319481 ) are plant codes for the interior trim color/type/material. I believe Wildjeff may have done research on these codes. What little I can find is: D - Trim level,deluxe

My '83 has D S 161609 just for example.

Speaking of the seats are they solid dark blue or are they multi-color with CAMARO on them (and repeated on the door panels)? This is what they should be and what 22D indicates in the '82-'87 Camaro Parts catalog for '83.
coolram62 is offline
Old 11-06-2008, 07:33 PM
  #6
Member
iTrader: (1)

wildjeff's Avatar

Join Date: Feb 2004
Location: Seattle
Posts: 480
Car: 1983 Trans Am
Engine: L69 5.0L HO
Transmission: Manual
Axle/Gears: 3.73
Re: Newbie Cowl Tag Codes?

I believe the last line decodes as:

D - Rear spoiler
B - Luggage compartment trim
W - Rear Wiper
N - Locking fuel door
S - Radio accommodation package

This is based on my personal observation so take it for what itís worth, nothing. I have never seen any definitive source (GM) on what they mean. Iím always looking for additional data.

and the 319481 is the schedule date. Note that its for GM internal use so it not a normal Julian date.
wildjeff is offline
Old 11-06-2008, 09:30 PM
  #7
Supreme Member
iTrader: (2)

coolram62's Avatar

Join Date: Dec 2005
Location: Beaufort South Carolina
Posts: 1,739
Car: 1983 Camaro Z/28
Engine: LU5 305 CFI
Transmission: 700R4
Axle/Gears: J65/G80/G92-3.23
Re: Newbie Cowl Tag Codes?

Thank you Wildjeff as I had hopes you would come on to see this thread. I was way off base on the "D" (should have used the search where this was discussed before) but that's the impression the parts catalog gave me as to it's meaning.

But what's weird is my '83 has the deluxe carpeted luggage compartment trim ,with the locking cover, but doesn't have the "B" on the trim tag. With GM they changed coding so often it's hard to keep track of.
coolram62 is offline
Old 11-07-2008, 12:12 AM
  #8
Member
iTrader: (1)

wildjeff's Avatar

Join Date: Feb 2004
Location: Seattle
Posts: 480
Car: 1983 Trans Am
Engine: L69 5.0L HO
Transmission: Manual
Axle/Gears: 3.73
Re: Newbie Cowl Tag Codes?

coolram62 - Thatís not weird, I might be wrong. That why the disclaimer B is one of the options Iím having trouble with. Iíll PM you, I have some questions and donít want to highjack this thread.
wildjeff is offline
Old 11-07-2008, 09:01 AM
  #9
Moderator

okfoz's Avatar

Join Date: Mar 2001
Location: Doghouse ∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑ Car: 1989 Formula 350 Vert Engine: 350 L98 Transmission: 700R4 Axle/Gears: B&W 3.27
Posts: 13,668
Car: 87 Formula T-Top, 87 Formula HT
Engine: 5.1L TPI, 5.0L TPI
Transmission: 700R4, M5
Axle/Gears: Sag 3.73, B&W 3.45
Re: Newbie Cowl Tag Codes?

WJ,
My 83 T/A has D & S, and it does have a Spoiler, The Radio I suspect was original as it was definately Circa 1983... It had the AM/FM Cassette...

Do you know how to decode the Schedule Date?

John
okfoz is offline
Old 11-08-2008, 02:20 PM
  #10
Member
iTrader: (1)

wildjeff's Avatar

Join Date: Feb 2004
Location: Seattle
Posts: 480
Car: 1983 Trans Am
Engine: L69 5.0L HO
Transmission: Manual
Axle/Gears: 3.73
Re: Newbie Cowl Tag Codes?

John - I don’t know how to decode the schedule date, I suspect its some sort of tracking code GM used internally that has no direct correlation to the Julian date the car was produced.

Most of the T/A and Z28s I have seen have only D and S, unless they where loaded.
wildjeff is offline
Old 11-12-2008, 10:18 PM
  #11
Junior Member
Thread Starter

Join Date: Nov 2008
Posts: 38
Re: Newbie Cowl Tag Codes?

Hi Guys.
Thank you so much.

I double checked and the seat code is definately AF9. Could someone help w/ that one? I accept the CC1 but the second letter sure could be taken to be a 'G'...... at least in the dark!

Everything else checks.

Now, is there anyone who can tell me if this car has a fuel filter? One more... Where do I get a center cap for one of the wheels?

Thank you for all your time.

Dan
Yakima, WA
dford is offline
Old 11-13-2008, 07:53 AM
  #12
Supreme Member
iTrader: (2)

coolram62's Avatar

Join Date: Dec 2005
Location: Beaufort South Carolina
Posts: 1,739
Car: 1983 Camaro Z/28
Engine: LU5 305 CFI
Transmission: 700R4
Axle/Gears: J65/G80/G92-3.23
Re: Newbie Cowl Tag Codes?

Dford the factory location for the CFI fuel filter is behind the alternator. I changed the routing of the lines on mine and now have the filter mounted on the frame rail next to the overflow tank. The fuel filter part numbers are WIX P/N 33478 and the Fram P/N G3694. You can also use the filter for a '84 CFI Corvette if you have to - I don't have the P/N at the moment.

Scottmoyer , Wildjeff or Okfoz will have to tackle the seat question as I'm at a loss to explain it.
coolram62 is offline
Old 11-13-2008, 09:58 AM
  #13
Junior Member
Thread Starter

Join Date: Nov 2008
Posts: 38
Re: Newbie Cowl Tag Codes?

Thank you so very much. I will look for the filter.

Dan
dford is offline
Old 07-28-2009, 08:35 AM
  #14
Junior Member
iTrader: (1)

Join Date: Jul 2009
Location: Greeneville Tennessee
Posts: 9
Re: Newbie Cowl Tag Codes?

I have a 1983 Z28 5.0 H O 5speed with functional hood (odd) and the dana 44 3.31 posi disc rear cowl tag is..ANY INFO WOULD HELP ,

D 03D 1FP87 N 145400
22C 27L 27U E
AR9 CC1
Z28 D80 PT
079590 059807
88MCLS is offline
Old 10-13-2018, 09:13 PM
  #15
Junior Member

jstadmud's Avatar

Join Date: Jan 2009
Location: North Carolina
Posts: 59
Car: 1987 IROC Z28
Engine: 5.0 liter
Transmission: 700R-4
Axle/Gears: 273 posi trac
Re: Newbie Cowl Tag Codes?

Originally Posted by 88MCLS View Post
I have a 1983 Z28 5.0 H O 5speed with functional hood (odd) and the dana 44 3.31 posi disc rear cowl tag is..ANY INFO WOULD HELP ,

D 03D 1FP87 N 145400
22C 27L 27U E
AR9 CC1
Z28 D80 PT
079590 059807


9 years later...... Does anyone have any info on this cowl tag??

My '83 Z28 5.0 CrossFire has a VERY similarly numbered tag as his:

D 05D 1FP87 N 167538
64R 59L 59U E
AR9
Z28 D80 PT
119684 522734

Does anyone know about these numbers?
jstadmud is offline
Old 02-09-2019, 10:43 AM
  #16
Junior Member

Join Date: Feb 2019
Posts: 2
Re: Help Please!

Originally Posted by dford View Post
I have an 83 T-Top Z28 w/ Cross-Fire 305 and Cowl fiberglass Hood. Could you help with mine?

D 04A 1FP87 L 132927
22D 11L 11U W
AF9 CG1
D B S 319481

Thank you so much.
For some reason I canít post a question on here. Hopefully this works! Can someone possibly help me decode my cowl tag? It would be greatly appreciated!

D 07C 1FP87 N 183657
7C 59L 59U E
AR9
Z28 D80 PT
1 37817 855892


thank you so much in advance!
inkzoo is offline
Old 02-09-2019, 11:19 AM
  #17
Supreme Member
iTrader: (28)

Drew's Avatar

Join Date: Jul 1999
Location: Salina, KS
Posts: 17,299
Re: Help Please!

Originally Posted by inkzoo View Post

For some reason I canít post a question on here. Hopefully this works! Can someone possibly help me decode my cowl tag? It would be greatly appreciated!

D 07C 1FP87 N 183657
7C 59L 59U E
AR9
Z28 D80 PT
1 37817 855892


thank you so much in advance!
D 1983
07C July Third week
1FP87 Chevy Camaro 2dr
N Norwood
183657 Body Number
7C interior trim
59L 59U Body color, Lower & Upper Beige
E Enamel
AR9 Reclining seats
Z28 Duh
D80 Rear spoiler
PT Party Time
1 37817 855892 Your lucky numbers.
Drew is offline
Old 02-09-2019, 11:27 AM
  #18
Supreme Member
iTrader: (28)

Drew's Avatar

Join Date: Jul 1999
Location: Salina, KS
Posts: 17,299
Re: Newbie Cowl Tag Codes?

Originally Posted by jstadmud View Post
9 years later...... Does anyone have any info on this cowl tag??

My '83 Z28 5.0 CrossFire has a VERY similarly numbered tag as his:

D 05D 1FP87 N 167538
64R 59L 59U E
AR9
Z28 D80 PT
119684 522734

Does anyone know about these numbers?
D 1983
05D May 4th week
1FP87 Chebby, Camaro, 2 doors
N Norwood
167538 Body Number
64R Interior Trim Vinyl Doeskin
59L 59U E Beige Enamel, upper & lower
AR9 reclining seats
Z28 D80 PT Z28 with a rear spoiler, PT?
119684 522734 Chinese Nuclear Launch Codes circa 4th week of May 1983.
Drew is offline
Old 02-09-2019, 11:30 AM
  #19
Supreme Member
iTrader: (28)

Drew's Avatar

Join Date: Jul 1999
Location: Salina, KS
Posts: 17,299
Re: Newbie Cowl Tag Codes?

Originally Posted by 88MCLS View Post
I have a 1983 Z28 5.0 H O 5speed with functional hood (odd) and the dana 44 3.31 posi disc rear cowl tag is..ANY INFO WOULD HELP ,

D 03D 1FP87 N 145400
22C 27L 27U E
AR9 CC1
Z28 D80 PT
079590 059807
D 03D 1983, March, 4th week
1FP87 Itsa Chebby Camaro with 2 doors!
N Narwood Ohio
145400 Body Number
22C Interior Trim Royal Blue Cloth
27L 27U E Dark Royal Blue Enamel
AR9 CC1 Reclining Buckets, T-tops
Z28 D80 PT Z28 with a rear spoiler
079590 059807 Combination to Dark Helmet's luggage.
Drew is offline
Old 02-10-2019, 08:49 AM
  #20
Moderator

scottmoyer's Avatar

Join Date: Jun 2000
Location: Florida
Posts: 7,807
Car: 87 IROC-Z, 82 Pace Car
Re: Newbie Cowl Tag Codes?

Really, Drew? Chinese launch codes? Luggage? Lucky numbers?

scottmoyer is offline
Old 02-10-2019, 09:32 AM
  #21
Supreme Member
iTrader: (28)

Drew's Avatar

Join Date: Jul 1999
Location: Salina, KS
Posts: 17,299
Re: Newbie Cowl Tag Codes?

You're right, I shouldn't joke. The gibberish numbers are simply the measurements of the Playmate of the month in which the cars were produced.
Drew is offline
Old 02-10-2019, 09:33 AM
  #22
Senior Member
iTrader: (1)

dagwood's Avatar

Join Date: Oct 2002
Location: Rockwell City, Iowa
Posts: 679
Car: 1982 Z28
Engine: LG4 305
Transmission: Auto
Re: Newbie Cowl Tag Codes?

Originally Posted by scottmoyer View Post
Really, Drew? Chinese launch codes? Luggage? Lucky numbers?

PT PARTY TIME

That was my favorite lmao
dagwood is offline
Old 02-10-2019, 09:43 AM
  #23
Supreme Member
iTrader: (28)

Drew's Avatar

Join Date: Jul 1999
Location: Salina, KS
Posts: 17,299
Re: Newbie Cowl Tag Codes?



It's a little known fact that back in the day, the factory installed a free promotional ham as a token of appreciation. Sadly the hams weren't publicized which led to many being removed from the car before the buyer could take delivery. All that remains now is the tell tale code on the body tag. PT right at the end, to remind the assembly line to install the ham.
Drew is offline
Old 02-10-2019, 09:48 AM
  #24
Senior Member
iTrader: (1)

dagwood's Avatar

Join Date: Oct 2002
Location: Rockwell City, Iowa
Posts: 679
Car: 1982 Z28
Engine: LG4 305
Transmission: Auto
Re: Newbie Cowl Tag Codes?

Originally Posted by Drew View Post


It's a little known fact that back in the day, the factory installed a free promotional ham as a token of appreciation. Sadly the hams weren't publicized which led to many being removed from the car before the buyer could take delivery. All that remains now is the tell tale code on the body tag. PT right at the end, to remind the assembly line to install the ham.
dagwood is offline
Old 02-12-2019, 08:46 AM
  #25
Moderator

okfoz's Avatar

Join Date: Mar 2001
Location: Doghouse ∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑∑ Car: 1989 Formula 350 Vert Engine: 350 L98 Transmission: 700R4 Axle/Gears: B&W 3.27
Posts: 13,668
Car: 87 Formula T-Top, 87 Formula HT
Engine: 5.1L TPI, 5.0L TPI
Transmission: 700R4, M5
Axle/Gears: Sag 3.73, B&W 3.45
Re: Newbie Cowl Tag Codes?

You made me laugh Drew.
okfoz is offline
Old 02-12-2019, 10:26 PM
  #26
Supreme Member
iTrader: (28)

Drew's Avatar

Join Date: Jul 1999
Location: Salina, KS
Posts: 17,299
Re: Newbie Cowl Tag Codes?

Originally Posted by okfoz View Post
You made me laugh Drew.
Good
Drew is offline
Old 02-12-2019, 11:23 PM
  #27
Junior Member

straightbuchana's Avatar

Join Date: Apr 2014
Location: White, Georgia
Posts: 47
Car: 82 Pontiac Trans Am
Engine: 350 Vortec, sprayed
Transmission: T56
Axle/Gears: Spooled Strange 12 bolt, 3.73 gears
Re: Newbie Cowl Tag Codes?

You actually had me convinced about the ham...
straightbuchana is offline
Related Topics
Thread
Thread Starter
Forum
Replies
Last Post
Jorlain
Exterior Parts Wanted
8
06-30-2017 12:04 AM
Falcon50
DFI and ECM
80
11-30-2016 03:55 AM
Cam-aro
Camaros Wanted
2
11-12-2015 04:35 PM
loud91rs
Camaros for Sale
7
10-05-2015 11:05 PM
Luigytico09
TPI
0
10-01-2015 09:46 AM


Thread Tools
Search this Thread
Quick Reply: Newbie Cowl Tag Codes?


Advertising
Featured Sponsors
Vendor Directory

Contact Us Advertising Cookie Policy Privacy Statement Terms of Service

© 2019 MH Sub I, LLC dba Internet Brands

We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.

  • Ask a Question
    Get answers from community experts
Question Title:
Description:
Your question will be posted in:
